Autonics CT6M-1P2, Digital Counter + Timer, W72xH72mm, 6-Digit LED, 1 Preset, PNP Or NPN Input, Prescale Value Setting
Autonics CT6M-1P2, Digital Counter + Timer, W72xH72mm, 6-Digit LED, 1 Preset, PNP Or NPN Input, Prescale Value Setting Autonics CT6M-1P2, Digital Counter + Timer, W72xH72mm, 6-Digit LED, 1 Preset, PNP Or NPN Input, Prescale Value Setting

Autonics CT6M-1P2, Digital Counter + Timer, W72xH72mm, 6-Digit LED, 1 Preset, PNP Or NPN Input, Prescale Value Setting

In stock
SKU
CT6M-1P2
Special Price ₹4,519.90 Regular Price ₹8,218.00
(18% GST Extra)
Add to Wish List
  • Display method : 6-digit 7-segment LED
  • Operation method : Counter: Count up, Count down, Count up/down Timer: Count up, Count down
  • Terminal : Terminal block
  • Output Operation : SIGNAL ON DELAY, POWER ON DELAY, FLICKER, INTERVAL, SIGNAL OFF DELAY, ON-OFF DELAY, INTEGRATION TIME
  • Power supply : 24VAC~ 50/60Hz, 24-48VDC
  • Protection structure : IP65(front panel)
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • Display method:6-digit 7-segment LED
  • Operation method:Counter: Count up, Count down, Count up/down, Timer: Count up, Count down
  • Terminal: Terminal block
  • Output Operation:SIGNAL ON DELAY, POWER ON DELAY, FLICKER, INTERVAL, SIGNAL OFF DELAY, ON-OFF DELAY, INTEGRATION TIME
  • Power supply: 24VAC~ 50/60Hz, 24-48VDC
  • Time operation:POWER ON START, SIGNAL ON START
  • External Power Supply:Max. 12VDC ±10%, 100mA
  • Signal Input Method:Voltage input(PNP), No-voltage input(NPN)
  • Max. Counting Speed: 1, 30, 1k, 5k, 10k [cps]
  • Min. signal Width:1ms/20ms
  • Memory Protection: Approx. 10 years
  • Setting range:0.001 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 1 min to 99 hour 59 min, 1 hour to 9999 hour
  • Control output_Type: 1-stage preset
  • Control output_Relay:SPDT (1c): 1
  • Control output_NPN open collector:2
  • Protection structure:IP65(front panel)
  • Counter_Counting range:-99999 to 999999
  • Counter_Scale:Decimal point up to fifth digit
  • Counter_Min. input signal width:RESET: Selectable 1ms/20ms
  • Timer_Min. input signal width:INA, RESET, INHIBIT, BATCH, RESET: Selectable 1ms/20ms
  • Environment_Ambient temperature:-10 to 55℃, storage: -25 to 65℃
  • Environment_Ambient humidity:35 to 85% RH, storage: 35 to 85% RH
  • Weight:Approx. 322g (approx. 252g)
