DC 3wire M8 Capacitive Proximity Sensor, Long-Distance Sensing Range 1-4mm, Diameter 8mm, PNP NO

In stock

SKU

BCR8-PN4

Special Price ₹2,372.50 Regular Price ₹3,650.00

(18% GST Extra)

Qty

Add to Wish List

Feature:

Reverse power polarity protection.
Surge protection function.
Over-current protection function.
Long life cycle and high reliability.
Able to check the status of operation by LED indicator.
Wide range of applications, including replacement of micro switches and limit switches.

Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

100% Secure Payment

Function: PNP Make (NO)
Detecting Distance: 1–4 mm (Adjustable)
Switching Hysteresis: Max. 15% of Sr
Standard Detecting Target: 8 × 8 × 1 mm (Iron)
Setting Distance: 4 mm ±10% (Adjustable)
Power Supply (Operating Voltage): 10–30 VDC
No-load Current: <10 mA
Response Frequency: 100 Hz
Residual Voltage: Max. 1.5 V
Temperature Drift: ±10% max. of detecting distance at +20°C (−25 to +70°C)
Max. Load Current: 100 mA (Overload protection point 280 mA)
Connection Type: Cable, 2 m
Housing Type: Cylindrical threaded (1 mm), 8 mm dia, length 45 mm
Housing Material: Stainless steel, sensing face – POM
Vibration & Shock: 1 mm amplitude at 10–55 Hz (X, Y, Z, 2 hrs); 500 m/s² (50G) in X, Y, Z (3 times)
Indicator: LED
Ambient Temperature: −25 to +70°C (non-freezing)
Storage Temperature: −30 to +80°C (non-freezing)
Ambient Humidity: 35–95% RH
Protection Circuit: Surge protection, overload & short-circuit protection
Protection: IP67
