BD-PN300F-LS||Laser Diffuse Photo Sensor, Sensing Range 300mm, PNP
BD-PN300F-LS||Laser Diffuse Photo Sensor, Sensing Range 300mm, PNP

BD-PN300F-LS||Laser Diffuse Photo Sensor, Sensing Range 300mm, PNP

In stock
SKU
BD-PN300F-LS
Special Price ₹2,112.50 Regular Price ₹3,250.00
(18% GST Extra)
Add to Wish List
  • Visible class 2 laser for diffuse sensor
  • Narrow effective beam provides small-object detection and precise position control
  • Excellent optical performance throughout sensing range, even close up
  • Bright LED operating status indicators are visible from 360º
  • Sensitivity adjustment
  • Glass window
  • Easy alignment
  • Easy retrofitting
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • Output Mode: PNP
  • Sensing Distance: 300mm (white paper 100x100)
  • Emitting Light: Infrared LED 660 nm
  • Operating Voltage: 12~24VDC ±10%
  • Current Consumption: <30 mA Max.
  • DC ripple: <10%
  • Load Current: 150ma Max. at 24VDC
  • No load current: <10mA
  • Leakage current: <0.01mA
  • Residual Voltage: <1.5CV
  • Operation mode: Dark on (NO)
  • Response Time: 5 ms Max.
  • Switching frequency: 120Hz
  • Switching hysteresis: <15% (sensing range)
  • Repeat accuracy: <5 to 10% (sensing range)
  • EMC: RFI>3V/M / EFT>1KV / ESD>4KV (contact)
  • Temperature drift: <10% (sensing range)
  • Short circuit protection: YES
  • Protection degree: IP55
  • Material active face: Filtrer mirror
  • Voltage With Standability: AC1000V 60Hz for 60 Sec.
  • Operating Temperature: -10°C ~ + 60°C
  • Ambient Humidity: 35% ~ 85% RH
  • Material: ABS
  • Wiring Method: Pre-wired Ø3.8 x 2 M / 3-wires
  • Weight: Approx. 70g
