BY-PT100F-Q||Small Diffuse Photo Sensor, Sensing Range 100mm, PNP

BY-PT100F-Q||Small Diffuse Photo Sensor, Sensing Range 100mm, PNP

BY-PT100F-Q||Small Diffuse Photo Sensor, Sensing Range 100mm, PNP

Be the first to review this product

In stock

SKU

BY-PT100F-Q

Special Price ₹3,510.00 Regular Price ₹5,400.00

(18% GST Extra)

Qty

Add to Wish List

Diffuse Photo Sensor
Visible RED Light is available at the distance of 100mm
Sensitivity adjuster
Small Rectangular, 100mm Sensing
PNP/NPN Light ON/Dark ON Selectable
Easy for installation & detection

Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

Sensing Type: Diffuse Reflection with Visible Light
Sensing Distance: 100mm
Emitting Light: Infrared LED 660 nm
Operating Voltage: 12~ 24VDC
Current Consumption: 25 mA Max.
Load Current: 100mA Max. at DC24V
Output type (selectable): PNP Light ON/ Dark ON
Response Time: 1 ms Max.
Insulation Resistance: 20MΩ min. (DC500V)
Voltage with standability: AC1000V 60Hz for 60 Sec.
Operating Temperature: -20°C ~ + 60°C
Ambient Humidity: 35% ~ 85% RH
Protection Degree: IP64
Material: ABS
Wiring method: Pre-weird Ø4.2 x 2 M / 4-wires
Weight: Approx. 60g
