GIC 4431AD1, 400VAC, 1 C/O,1K to 200K Sensitivity, Draining & Filling, Liquid Level Controller
Out of stock
SKU
4431AD1
Special Price
₹1,121.40
Regular Price
₹1,602.00
FREE SHIPPING
Free Shipping by Surface Only*
SECURE PAYMENT
100% Secure Payment
| Datasheet | |
|---|---|
| Supply Voltage | 415VAC, +/-20% |
| Frequency | 47Hz - 63Hz |
| Power Consumption (Max.) | 3VA |
| Device Characteristics | Conductive Sensor Probes Stainless Steel SS304, 3 or 6 Nos |
| Sensor Length | 10 cm |
| Control Action Modes | Only Draining, Only Filling, Draining & Filling Simultaneous (One Tank or Two tanks) |
| Sensitivity | 1K to 200 K Ohm (Potentiometer adjustable) |
| Sensor Voltage & Current | 12 Vp-p, 100 Hz, < 1 mA |
| Sensor Cable |
Cable gauge (Min): 0.5 sq mm Tin coated Cable dia (Min): 1.5 mm Max Cable Length - 1000m (For set value < 50%) Max Cable Length - 300m (For set value 100%) Max capacitances of wire - 80 nF / km |
| Settable ON & OFF Delay Time | 0.5 sec to 10 sec |
| Manual Start Switch | If Lower tank water level is greater than Low level & upper tank water level is below High level then by pressing a switch Relay can be switched ON manually. |
| Output Control Mode | Relay ON/OFF |
| Contact Ratings |
1 C/O, 8A @ 250VAC, Resistive Terminal 15 - Pole Terminal 16 - NC Terminal 18 - NO |
| Utilization Category |
AC-15: Rated Voltage (Ue): 120/240V, Rated Current (Ie): 3.0/1.5A DC-13: Rated Voltage (Ue): 24/125/250V, Rated Current (Ie): 2.0/0.22/0.1A |
| Electrical Life | 1 x 105 Operations |
| Mechanical Life | 1 x 107 Operations |
| LED Indication | GREEN LED: Power ON RED LED: Relay Output ON |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -10°C to +70°C |
| Relative Humidity | 5 to 95 % RH (non condensing) |
| Mounting | Base / DIN Rail |
| Dimensions (W x H x D) | 36 x 90 x 65 mm |
| Certification | RoHS Compliant |
