Schneider LV510315, MCCB, EasyPact CVS100B, 25 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4 Pole
Schneider LV510315, MCCB, EasyPact CVS100B, 25 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4 Pole Schneider LV510315, MCCB, EasyPact CVS100B, 25 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4 Pole Schneider LV510315, MCCB, EasyPact CVS100B, 25 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4 Pole

Schneider LV510315, MCCB, EasyPact CVS100B, 25 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 4 Pole

In stock
SKU
LV510315
Special Price ₹5,112.00 Regular Price ₹12,780.00
(18% GST Extra)
Add to Wish List
  • 4P 3D fixed circuit breaker for small and medium-sized building protection.
  • Breaking capacity: 25kA rms at 415VAC 50/60Hz; Operational voltage: 440VAC 50/60Hz.
  • 63A thermal-magnetic (TMD) trip unit with adjustable thermal and fixed magnetic protection.
  • Dimensions: 140mm x 161mm x 86mm; supports optional functions and accessories.
  • Compliant with IEC 60947, CCC, EAC; Class II front face device suitable for Class II switchboards.
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

EasyPact CVS100B Specifications
Main
RangeEasyPact
Range of productEasyPact CVS100...250
Product nameEasyPact CVS
Device short nameCVS100B
Product typeCircuit breaker
Device applicationDistribution
Poles description4P
Protected poles3D
Earth leakage protectionWithout
Rated current [In]63 A at 40 °C
Network typeAC
Utilisation categoryCategory A
Breaking capacity [Icu] 40 kA at 220/240 V AC
25 kA at 380/415 V AC
20 kA at 440 V AC
Trip unitTM-D, Thermal-magnetic, 63 A
Protection typeOverload (thermal), Short-circuit (magnetic)
Complementary
Rated impulse voltage [Uimp]8 kV
Network frequency50/60 Hz
Breaking capacity codeB
Rated service breaking capacity [Ics] 15 kA at 440 V AC
25 kA at 380/415 V AC
40 kA at 220/240 V AC
Neutral positionLeft
Mechanical durability30,000 cycles
Electrical durability12,000 cycles at 415 V
Control typeToggle
Thermal protection range44.1…63 A
Neutral protection settingNo protection (3D)
Long time pick-upAdjustable 0.7–1 x In
Instantaneous pick-upFixed 500 A
Contact position indicatorYes
MountingBackplate, Fixed
ConnectionsScrew connection, Front
Dimensions (W×D×H)140 × 86 × 161 mm
