Selec ELCTR35-1-30mA-230V, Three Phase Earth Leakage Relay with Inbuilt CBCT (30mA Fixed). Size 74mm, DIN Rail Mount
Selec ELCTR35-1-30mA-230V, Three Phase Earth Leakage Relay with Inbuilt CBCT (30mA Fixed). Size 74mm, DIN Rail Mount

Selec ELCTR35-1-30mA-230V, Three Phase Earth Leakage Relay with Inbuilt CBCT (30mA Fixed). Size 74mm, DIN Rail Mount

Out of stock
SKU
ELCTR35-1-30mA-230V
Special Price ₹797.28 Regular Price ₹1,661.00
(18% GST Extra)
  • 3 phase leakage current measurement device with inbuild (CBCT)
  • Accuracy : 5% of input current
  • 1 C/O (SPDT) output relay
  • Trip setting: 75% of 30mA
  • LED indications : Power supply and fault recognition
  • Supply Voltage : 230V±15%
  • CE certified

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • Measuring Parameter: Monitors True RMS Earth Leakage Current
  • Electrical Connection: 3Ø-4W, 1Ø-2W, 3Ø-3W
  • Trip Setting: 75% of 30mA
  • Time Ranges: Reset Time: Instantaneous
  • Accuracy: Trip: ±5% of Input Current, Time: ±5% of Response Time
  • Output Contact: 1 C/O (SPDT )
  • Output Rating: NO: 5A@250VAC, NC: 5A@30V DC
  • Supply Voltage: 230V AC (±15%)
  • Size: 74mm
  • Mounting Type: DIN Rail Mount
  • Certification: CE
