Selec FL-SC-TO08, Modular type PLC - Flexys IO Cards, 8 Channel Transistor Output Card, Plug Type
Selec FL-SC-TO08, Modular type PLC - Flexys IO Cards, 8 Channel Transistor Output Card, Plug Type

Selec FL-SC-TO08, Modular type PLC - Flexys IO Cards, 8 Channel Transistor Output Card, Plug Type

In stock
SKU
FL-SC-TO08
Special Price ₹1,311.36 Regular Price ₹2,732.00
(18% GST Extra)
Add to Wish List
  • Plug in module
  • Easy to connect & replace in Flexys GT35, Flexys rail, Flexys Panel TX4 & EXP FLEX 2M
  • Configured via selpro software
  • Spring type pluggable terminals
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • No of outputs: 8 Nos
  • Output type: PNP
  • Related Voltage: 100 mA at 24VDC
  • Output current: 100mA max. per output
  • Response time: 10 ms (Selectable through software via debounce parameter
  • Short circuit protection : Yes
  • Reverse polarity protection : Yes
  • Isolation between outputs : 2.5kV
  • Ambient operating temperature: 0°C to 55°C
  • Ambient storage temperature: -20°C to 70°C
  • Humidity: 95%
  • Weight: 40gms
Product Code Description Certification
FL-SC-AI03-NTC-AI03-I 3 Channel Analog Input - NTC, 3 Channel Analog Input - Current Card CE, RoHS In process
FL-SC-AI03-U-AO02-U 3 Channel Analog Input Universal, 2 Channel Analog Output Universal Card CE, RoHS In process
FL-SC-AI04-RTD 4 Channel Analog Input Card RTD (PT-100) CE, RoHS
FL-SC-AI04-TC 4 Channel Differential Analog Input Card Thermocouple CE, RoHS
FL-SC-AI04-U 4 Channel Analog Input Card Universal CE, RoHS In process
FL-SC-AI06-I 6 Channel Analog Input Card Current CE, RoHS
FL-SC-AI06-V 6 Channel Analog Input Card Voltage CE, RoHS
FL-SC-AIDF04-TC 4 Channel Differential Analog Input Card Thermocouple CE, RoHS
FL-SC-AO04-I 4 Channel Analog Output Card Current CE, RoHS
FL-SC-AO04-V 4 Channel Analog Output Card Voltage CE, RoHS
FL-SC-DI04-RO04 4 Digital Input, 4 Relay Output Card CE, RoHS
FL-SC-DI10 10 Digital Inputs Card CE, RoHS
FL-SC-DI14 14 Digital Inputs Card CE, RoHS
FL-SC-LC04 4 Channel Load Cell input card CE, RoHS In process
FL-SC-RO08 8 Channel Relay Output Card CE, RoHS
FL-SC-TO08 8 Channel Transistor Output Card CE, RoHS
