Selec HTC405, 3 Digit Single Display Humidity + Temperature Controller, RH/RTD Sensor Input 2 Relay Control Output, Size 36x72mm, Panel Mount
Selec HTC405, 3 Digit Single Display Humidity + Temperature Controller, RH/RTD Sensor Input 2 Relay Control Output, Size 36x72mm, Panel Mount

Selec HTC405, 3 Digit Single Display Humidity + Temperature Controller, RH/RTD Sensor Input 2 Relay Control Output, Size 36x72mm, Panel Mount

In stock
SKU
HTC405
Special Price ₹2,075.52 Regular Price ₹4,324.00
(18% GST Extra)
Add to Wish List
  • 3 digit single display with RH input
  • Capacitive touch display
  • RH sensor enclosed with unit
  • ON-OFF control for humidity
  • 7A SPDT Relay output
  • 0% - 100% Humidity control range
  • CE certified
  • 3 digit LED display
  • RTD(PT100) input
  • ON-OFF/PID control for temperature
  • Auto tune / Self tune PID
  • 7A SPDT Relay output
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • Display Type: 7 Segment LED, Single White Display
  • Display Configuration: 3 Digits
  • Type of Inputs: 5V RH (HS-A-100) sensor for Humidity, RTD(PT100) sensor for Temperature
  • Resolution: 1/0.1
  • Accuracy: RTD: ±0.25% of span or 1° whichever is greater (20min of warm up time), Cold Junction calibration accuracy for RTD input 0.1% of F.S ¬± 1¬∞ C, Humidity: ¬±3% for RH 10% to 80%, ¬±4% for below 10% or above 80%.
  • Type of Output: Relay
  • Set Point: 2
  • Control Mode: For Humidity: ON-OFF, For Temperature:ON-OFF / PID control
  • Features: Load protection protocol, Low / High Alarm, Free RH sensor with unit
  • Supply Voltage: 90-270V AC/DC
  • Size: 36 x 72mm
  • Mounting Type: Panel Mount
  • Certification: CE, IP65 frontal
