Selec LRPS-240-48, 240Watt 24V/10A Power Supply, DIN Rail Mount, Plastic Housing
Selec LRPS-240-48, 240Watt 24V/10A Power Supply, DIN Rail Mount, Plastic Housing

Selec LRPS-240-48, 240Watt 24V/10A Power Supply, DIN Rail Mount, Plastic Housing

Out of stock
SKU
LRPS240-48
Special Price ₹2,652.48 Regular Price ₹5,526.00
(18% GST Extra)
  • Low Cost CVCC Power Supply
  • Efficiency up to 87%
  • Designed to meet UL 508 & IEC 62368-1
  • Cooling by built-in DC Fan

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • DC output Voltage, Current: 48V / 10A
  • Input Voltage: 170 - 264 VAC (240 - 370 VDC)
  • Input Frequency: 50/60 Hz
  • Inrush Current: < 60 A; Measured at 264 VAC, 25°C Ambient, Cold start
  • Output Voltage: 48V
  • Output Power: 240 W
  • Voltage Tolerance: ± 1 %
  • Line Regulation: ± 1 %
  • Load Regulation:± 1 %
  • Turn On Time: < 3 sec, full load
  • Hold Up Time: > 30 m sec at 230 VAC, Full Load
  • Rise Time: < 100ms
  • Overload Protection: 11 A to 11.5 A of Constant Current type down to 18 VDC output; Hiccup mode for heavy overload ; Auto recovery
  • Output Short Circuit Protection: Hiccup mode when output is shorted; Auto recovery type
  • Operating Temperature: -25°C to + 70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C, - 25°C to 0°C startup is guaranteed with specification deviation ( Output ripple can be more than 10 % of the output voltage. )
  • Storage Temperature: -40°C to +85°C
  • Cooling: Cooling by Built-in DC Fan
  • Humidity: 5 to 95 % RH, Non condensing
  • Altitude: 2000 m
  • Dimension: 60 x 154 x 158.55 mm(W x H x D)
  • Weight: 680gms
  • Mounting: 35 mm DIN Rail
Product Code Description Certification
LRPS240-24 240 W, 24 V / 10 A DIN rail mounted Power Supply in Plastic Housing -
LRPS240-48 240 W, 48 V / 5 A DIN rail mounted Power Supply in Plastic Housing -
