Selec PPRA-4M-3-415V, Three Phase Analog Pump protection relay, DIN Rail Mount, 415VAC
Selec PPRA-4M-3-415V, Three Phase Analog Pump protection relay, DIN Rail Mount, 415VAC

Selec PPRA-4M-3-415V, Three Phase Analog Pump protection relay, DIN Rail Mount, 415VAC

In stock
SKU
PPRA-4M-3-415V
Special Price ₹1,239.84 Regular Price ₹2,853.00
(18% GST Extra)
Add to Wish List
  • Monitors: Phase loss, Phase unbalance, Phase sequence, Overload trip current, Under / Over current in 1Ø and 3Ø Pumps.
  • 1 C/O SPDT relay.
  • Auto / Remote test available.
  • MPCT range : 10A - 80A
  • Operating range : 280 -500V AC
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • Measuring Parameter: Monitors Over Load (As per NEMA Curve), Over Current, Under Current / Dry run, Locked current, Over voltage, Under Voltage, Phase failure
  • Electrical Connection: 1Ø - 2
  • Test / Reset: Manual / Auto reset
  • LED Indication: Power ON, Current and Voltage parameter
  • Voltage Measuring Range: 180 to 300V AC (L - N)
  • Power Consumption: 40VA (max)
  • Motor Rated Current Measuring: 1A to 30A
  • Output Contact: Control Output 1 NO Relay, Relay Rating 30A@277V AC
  • Accuracy: Current Accuracy ±5% of rated current, Voltage Accuracy ±1% of 300V, Time Accuracy ±5% ±100msec
  • Functional Specifications: Over Load NEMA class 5, 10, 15, 20, 30, Over Current Ranges 10% - 70% of Ir (Rated Current), Under Current 20% - 80% of Ir (Rated Current), Locked Current / Stall Current Fixed : 300% of Ir (Rated Current), Over Voltage Fixed (280V), Under Voltage Fixed (180V), Phase Loss Yes (<160V)
  • Time Setting: Power ON Delay 1sec (Fixed)Trip Time Delay 0, 2, 4, 6, 8 & 10 sec,(Current & Voltage parameters), Auto Reser Time 15min, (Current & Voltage parameters), Phase Loss Trip Time Instantaneous (<120ms)
  • Auto Restart Attempts: 3 (Fixed)
  • Mounting: DIN Rail Mount
  • Size: DIN 66.50 x 70 x 90 (H x W x L)

No specifications available for this product.
