Selec RPS15-05-CE, 15Watt 5 Volt/2.4A Current Power Supply, DIN Rail Mount
Selec RPS15-05-CE, 15Watt 5 Volt/2.4A Current Power Supply, DIN Rail Mount

Selec RPS15-05-CE, 15Watt 5 Volt/2.4A Current Power Supply, DIN Rail Mount

In stock
SKU
RPS15-05-CE
Special Price ₹663.84 Regular Price ₹1,383.00
(18% GST Extra)
Add to Wish List
  • Supports 90 - 264 VAC / 127 - 370 VDC
  • Efficiencies up to 82 %
  • Protection against short circuit, overload
  • Cooling by free air convection
  • Full power between -25°C to +50°C
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • DC output Voltage, Current: 5V / 2.4A
  • Input Voltage: 90 - 264 VAC (127 - 370 VDC)
  • Input Frequency: 50/60 Hz
  • Inrush Current: < 30 Amps; Measured at 264 VAC, 25°C Ambient, Cold start
  • Output Power: 15 W
  • Voltage Tolerance: ± 1 %
  • Line Regulation: ± 1 %
  • Load Regulation: ± 1 %
  • Turn On Time: <1 sec, full load
  • Hold Up Time: 30 ms @ 230 VAC & 10 ms @ 115 VAC, full load
  • Rise Time: < 100 ms
  • Overload Protection: 110 % to 150 % of rated output current; Hiccup type, Autorecovery
  • Output Short Circuit Protection: Hiccup mode when output is shorted; Autorecovery type
  • Operating Temperature: -40°C to +70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C. Note: (Only start up guaranteed at -40°C with spec deterioration.)
  • Storage Temperature: -40°C to +85°C
  • Cooling: Natural convection cooled
  • Humidity: 5 to 95 % RH, Non condensing
  • Altitude: 2000 m
  • Dimension: 17.5 x 90 x 65 mm(W x H x D)
  • Weight: < 100 gms
  • Mounting: 35mm DIN Rail
Product Code Description Certification
RPS15-05-CE 12 W, 05 V / 2.4 A DIN rail mounted Power Supply in Plastic Housing CE
RPS15-12-CE 15 W, 12 V / 1.25 A DIN rail mounted Power Supply in Plastic Housing CE
RPS15-24-CE 15 W, 24 V / 0.63 A DIN rail mounted Power Supply in Plastic Housing CE
