Selec RPS15-12-CE, 15Watt 12 Volt/ 1.25A Current Power Supply, DIN Rail Mount
Out of stock
SKU
RPS15-12-CE
Special Price
₹694.56
Regular Price
₹1,447.00
FREE SHIPPING
Free Shipping by Surface Only*
SECURE PAYMENT
100% Secure Payment
- DC output Voltage, Current: 12V / 1.25A
- Input Voltage: 90 - 264 VAC (127 - 370 VDC)
- Input Frequency: 50/60 Hz
- Inrush Current: < 30 Amps; Measured at 264 VAC, 25°C Ambient, Cold start
- Output Power: 15 W
- Voltage Tolerance: ± 1 %
- Line Regulation: ± 1 %
- Load Regulation:± 1 %
- Turn On Time: < 1 sec, full load
- Hold Up Time: 30 ms @ 230 VAC & 10 ms @ 115 VAC, full load
- Rise Time: < 100 ms
- Overload Protection: 110 % to 150 % of rated output current; Hiccup type, Autorecovery
- Output Short Circuit Protection: Hiccup mode when output is shorted; Autorecovery type
- Operating Temperature:-40°C to +70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C. Note : Only start up guaranteed at -40°C with spec deterioration.
- Storage Temperature: -40°C to +85°C
- Cooling: Natural convection cooled
- Humidity: 5 to 95 % RH, Non condensing
- Altitude: 2000 m
- Dimension: 17.5 x 90 x 65 mm(W x H x D)
- Weight: < 100 gms
- Mounting: 35 mm DIN Rail
| Product Code | Description | Certification |
|---|---|---|
| RPS15-05-CE | 12 W, 05 V / 2.4 A DIN rail mounted Power Supply in Plastic Housing | CE |
| RPS15-12-CE | 15 W, 12 V / 1.25 A DIN rail mounted Power Supply in Plastic Housing | CE |
| RPS15-24-CE | 15 W, 24 V / 0.63 A DIN rail mounted Power Supply in Plastic Housing | CE |
