Selec RPS15-24-CE, 15Watt 24 Volt/ 0.63A Current Power Supply, DIN Rail Mount
In stock
SKU
RPS15-24-CE
Special Price
₹694.56
Regular Price
₹1,447.00
Check Delivery Options at your Area
FREE SHIPPING
Free Shipping by Surface Only*
SECURE PAYMENT
100% Secure Payment
| Input Voltage | 90 - 264 VAC (127 - 370 VDC) |
| Input Frequency | 50/60 Hz |
| Inrush Current | < 30 Amps; Measured at 264 VAC, 25°C Ambient, Cold start |
| Output Voltage/Current | 24 V / 0.63A |
| Output Power | 15 W |
| Voltage Tolerance | ± 1 % |
| Line Regulation | ± 1 % |
| Load Regulation | ± 1 % |
| Turn On Time | < 1 sec, full load |
| Hold Up Time | 30 ms @ 230 VAC & 10 ms @ 115 VAC, full load |
| Rise Time | < 100 ms |
| Overload Protection | 110 % to 150 % of rated output current; Hiccup type, Autorecovery |
| Output Short Circuit Protection | Hiccup mode when output is shorted; Autorecovery type |
| Operating Temperature | -40°C to +70°C; De-rate linearly above 50°C from 100 % load at 50°C to 50 % load at 70°C. Note : Only start up guaranteed at -40°C with spec deterioration. |
| Storage Temperature | -40°C to +85°C |
| Cooling | Natural convection cooled |
| Humidity | 5 to 95 % RH, Non condensing |
| Altitude | 2000 m |
| Dimension | 17.5 x 90 x 65 mm(W x H x D) |
| Weight | < 100 gms |
| Mounting | 35 mm DIN Rail |
| Product Code | Description | Certification |
|---|---|---|
| RPS15-05-CE | 12 W, 05 V / 2.4 A DIN rail mounted Power Supply in Plastic Housing | CE |
| RPS15-12-CE | 15 W, 12 V / 1.25 A DIN rail mounted Power Supply in Plastic Housing | CE |
| RPS15-24-CE | 15 W, 24 V / 0.63 A DIN rail mounted Power Supply in Plastic Housing | CE |
