Selec VFD-SH-3-075-B-415V, Three Phase Heavy Duty AC Drives, 415VAC INPUT, 3 Phase 415VAC OUTPUT, 7.5 HP /5.5kW /13Amp Output
In stock
SKU
VFD-SH-3-075-B-415V
Special Price
₹18,560.16
Regular Price
₹38,667.00
Selec VFD-SH-3-075-B-415V, Three Phase Heavy Duty AC Drives, 415VAC INPUT, 3 Phase 415VAC OUTPUT, 7.5 HP /5.5kW /13Amp Output is available to buy in increments of 1
Check Delivery Options at your Area
FREE SHIPPING
Free Shipping by Surface Only*
SECURE PAYMENT
100% Secure Payment
- AC Input Voltage Range: Three Phase
- Applicable motor output (kW): 5.5
- Applicable motor output (HP): 7.5
- Maximum input current: 24A
- Rated output capacity (kVA): 9.3
- Rated output current: 13A
- Frequency Range: 50/60 Hz
- Control Mode: Space vector PWM (SVPWM)-based scalar control
- Frequency Control Range: 0.1 to 400 Hz
- Acc./Dec. Time: 0.1 to 3600.0 sec., four acceleration and deceleration time settings available
- Overload Capacity: For ND: 120% up to 60 sec, 150% up to 10 sec, 180% up to 1 sec (every 10 min) For HD: 150% up to 60 sec, 180% up to 10 sec, 200% up to 1 sec (every 10 min)
- Protection functions: Over voltage, Under voltage, Over current, Over temperature, Over load, Under current and Output short circuit
- Ingress Protection: IP20
- Working Temperature: -10 to +55 °C
- Ambient humidity: <90%, No condensation
- Installation location: Indoor, <1000m altitude above sea level
| Product Code | Description | Output Current |
|---|---|---|
| VFD-S-3-010-415V | 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT
