Selec VFD-SH-3-200-B-415V, Three Phase Heavy Duty AC Drives, 415VAC INPUT, 3 Phase 415VAC OUTPUT, 20 HP /15kW /32Amp Output
Selec VFD-SH-3-200-B-415V, Three Phase Heavy Duty AC Drives, 415VAC INPUT, 3 Phase 415VAC OUTPUT, 20 HP /15kW /32Amp Output

Selec VFD-SH-3-200-B-415V, Three Phase Heavy Duty AC Drives, 415VAC INPUT, 3 Phase 415VAC OUTPUT, 20 HP /15kW /32Amp Output

Be the first to review this product
In stock
SKU
VFD-SH-3-200-B-415V
Special Price ₹30,982.56 Regular Price ₹64,547.00
(18% GST Extra)
Add to Wish List
  • 4 pre-set V/f modes; 1 user-defined V/f program
  • Input: Three phase 415V AC, 50/60 Hz
  • Output: Three phase 415V AC, 0 to 400 Hz
  • Output power: 20 HP (15 kW)
  • 8 (PNP/NPN) Inputs, 2 Analog Inputs (0-10 V/0-20 mA/4-20 mA), 2 Relay Outputs, 1 Analog Output (0-10 V/0-20 mA), and 2 Open Collector Outputs
  • Supports the RS485 Modbus Communication Protocol
  • Protection against Over voltage, Under voltage, Over temperature, Over load, Under current, Over current and Short circuit
  • Suitable for applications like pumps, fans, conveyors, food and drink packaging machinery, industrial washing machines, and most general industries, etc.
Check Delivery Options at your Area

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

  • AC Input Voltage Range: Three Phase
  • Applicable motor output (kW): 15
  • Applicable motor output (HP): 20
  • Maximum input current: 63A
  • Rated output capacity (kVA): 23
  • Rated output current: 32A
  • Frequency Range: 50/60 Hz
  • Control Mode: Space vector PWM (SVPWM)-based scalar control
  • Frequency Control Range: 0.1 to 400 Hz
  • Acc./Dec. Time: 0.1 to 3600.0 sec., four acceleration and deceleration time settings available
  • Overload Capacity: For ND: 120% up to 60 sec, 150% up to 10 sec, 180% up to 1 sec (every 10 min) For HD: 150% up to 60 sec, 180% up to 10 sec, 200% up to 1 sec (every 10 min)
  • Protection functions: Over voltage, Under voltage, Over current, Over temperature, Over load, Under current and Output short circuit
  • Ingress Protection: IP20
  • Working Temperature: -10 to +55 ¬∞C
  • Ambient humidity: <90%, No condensation
  • Installation location: Indoor, <1000m altitude above sea level
Product Variants
Product Code Description Output Current
VFD-S-3-010-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 1 HP/0.75 kW 2.5 A
VFD-S-3-020-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 2 HP/1.5 kW 3.7 A
VFD-S-3-030-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 3 HP/2.2 kW 5.1 A
VFD-SH-3-050-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 5 HP/3.7 kW, Heavy Duty 9 A
VFD-SN-3-075-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 7.5 HP/5.5 kW, Normal duty 17 A
VFD-SH-3-075-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 7.5HP/5.5kW, Heavy duty 13 A
VFD-SN-3-100-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 10HP/7.5kW, Normal Duty 25 A
VFD-SH-3-100-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 10HP/7.5kW. Heavy Duty 17 A
VFD-SH-3-150-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 15HP/11kW. Heavy Duty 25 A
VFD-SN-3-200-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 20 HP/15 kW, Normal duty 37 A
VFD-SH-3-200-B-415V 3 Phase 415V AC INPUT, 3 Phase 0 to 415V AC OUTPUT, 20 HP/15 kW, Heavy duty 32 A
Reviews
Write Your Own Review
You're reviewing:Selec VFD-SH-3-200-B-415V, Three Phase Heavy Duty AC Drives, 415VAC INPUT, 3 Phase 415VAC OUTPUT, 20 HP /15kW /32Amp Output
Your Rating
Downloads
document VFD-SH-3-200-B-415V-Datasheet (573.87 kB)
document VFD-SH-3-200-B-415V-Instruction Manual (13.76 MB)
