BU-06KN||K type, 6mm Slot U-Shape Photo Sensor, Connector type, NPN Output
In stock
SKU
BU-06KN
Special Price
₹633.75
Regular Price
₹975.00
Check Delivery Options at your Area


FREE SHIPPING
Free Shipping by Surface Only*


SECURE PAYMENT
100% Secure Payment
- Output Type: NPN Light ON /Dark ON Selectable
- Sensing Distance: 6mm
- Emitting Light: Infrared LED 940 nm
- Beam Axis: 0.8x2mm width
- Operating Voltage: 10~30VDC
- Current Consumption: 15 mA Max.
- Load Current: 100ma Max. at 24VDC
- Response Time: 0.5 ms Max.
- Insulation Resistance: 20MΩ min. (DC500V)
- Voltage With Standability: AC1000V 60Hz for 60 Sec.
- Operating Temperature: 0°C ~ + 60°C
- Ambient Humidity: 35% ~ 85% RH
- Material: ABS
- Protection Degree: IP50
- Option: CT-04
- Weight: Approx. 4g
