BZ-PN20FF||Diffuse Micro Photo Sensor, Sensing Range 20mm, PNP
In stock
SKU
BZ-PN20FF
Special Price
₹1,478.75
Regular Price
₹2,275.00
Check Delivery Options at your Area
FREE SHIPPING
Free Shipping by Surface Only*
SECURE PAYMENT
100% Secure Payment
- Output Mode: PNP
- Sensing Distance: 20mm (black non-glossy 10x10 cm)
- Emitting Light: Infrared LED 940 nm
- Operation Mode: PNP NO (Dark on) / NC (Light on) Selectable
- Operating Voltage: 12~24VDC
- Current Consumption: 25 mA Max.
- Load Current: 100ma Max. at 24VDC
- Response Time: 1 ms Max.
- Ambient illumination: 6,000 lux max.
- Insulation Resistance: 20MΩ min. (DC500V)
- Voltage With Standability: AC1000V 60Hz for 60 Sec.
- Operating Temperature: -20°C ~ + 45°C
- Ambient Humidity: 35% ~ 85% RH
- Material: PC
- Wiring Method: CT-04 (Optional)
- Weight: Approx. 3g
No specifications available for this product.
