Selec XTC562, 6+6 Digit Dual Display, Multifunction Digital Timer + Counter, Size 48x48mm, Panel Mount

Selec XTC562, 6+6 Digit Dual Display, Multifunction Digital Timer + Counter, Size 48x48mm, Panel Mount

Selec XTC562, 6+6 Digit Dual Display, Multifunction Digital Timer + Counter, Size 48x48mm, Panel Mount

Be the first to review this product

Out of stock

SKU

XTC562

Special Price ₹1,960.32 Regular Price ₹4,084.00

FREE SHIPPING

Free Shipping by Surface Only*

SECURE PAYMENT

100% Secure Payment

Display Type	6 (White) + 6 (Orange) digits dual display
Relay Contact	2 SPDT
Range	Timer : 9999.99/99999.9/999999 sec, 9999.59 min : sec / 99999.9 min, 999999 min 9999.59 hr: min / 9 9999.9/999999 hr Counter : Selectable least count 0.0001, 0.001, 0.01, 0.1 &1
Operating Modes	Timer : On delay, Interval, Cyclic On first, Cyclic Off first, Instantaneous + Delayed at start pulse, Instantaneous + Delayed at power on, Motor reverse, Batch. Counter : ON delay, Interval, Time pulse repeat, Auto reset Rate : HA / LA / BAND
Start Input	Pulse, Gate, Level
Reset	Front, Remote
Counting Direction	Unidirectional, Bi – directional, Quadrature
Features	Memory Retention, Batch Counting, Rate Indication
Sensor type	NPN, PNP, Potential Free Contact
Supply Voltage	90 to 270V AC / DC
Size	48 x 48 mm
Mounting Type	Panel Mount
Certification	CE

Product Variants

Product Code	Output 1	Output 2	Supply Voltage	Certification
XTC562	Relay (5A)	Relay (5A)	90 to 270V AC/DC	CE
