KT-09P-1M||Magnetic Sensors For Hydraulic & Pneumatic Cylinders
Out of stock
SKU
KT-09P-1M
Special Price
₹1,624.86
Regular Price
₹2,708.10


FREE SHIPPING
Free Shipping by Surface Only*


SECURE PAYMENT
100% Secure Payment
- Wiring Method: 3-Wire Type
- Switching Logic: Solid State Output Normally Open
- Sensor Type: PNP Current Sinking
- Operating Voltage: 5 ~ 30 V DC
- Switching Current: 1 Amp. max.
- Contact Rating: 30 W max.
- Current Consumption: 30 mA @ 24 V DC max.
- Voltage Drop: 1.5 V @ 0.5 A max.
- Leakage Current: 0.01 mA max.
- Indicator: Green LED , Output : Red LED
- Cable: ø4.5, 3C, PVC
- Operating Frequency: 1000Hz
- Magnet Requirement: 40 Gauss
- Temperature Range: -10 ~ 70 ˚C
- Shock: 50 G
- Vibration: 9 G
- Enclosure Classification: IEC 60529 IP67
- Protection Circuit: 3,4
No specifications available for this product.
